Description

The Audio-Technica AT-VM745xML VMx microlinear phono cartridge takes your vinyl to the next level with razor-sharp detail and responsive, lifelike sound. Built with a dual moving magnet design that mimics the cutter head, it offers high channel separation and exceptional accuracy. A solid boron cantilever and microlinear stylus work in tandem to track grooves with unmatched precision, minimizing wear while capturing the full depth and nuance of every record in your collection.

AT-VM745xML With PCUHD Coils and Paratoroidal Design

At the core of this cartridge is a paratoroidal coil structure—two coils per channel, carefully stacked for maximum efficiency. PCUHD (Pure Copper Ultra High Drawability) wiring improves conductivity and transient response, while a center shield plate reduces crosstalk and strengthens stereo imaging. Whether you're spinning jazz, classical or modern vinyl, the result is a three-dimensional soundstage with striking clarity and dynamic balance.

Audio-Technica Cartridge With Aluminum Housing and Threaded Mount

Built for both performance and ease of use, the die-cast aluminum body keeps resonance in check while delivering rock-solid signal transmission. Threaded inserts allow for fast, nut-free installation with just two screws, and the stylus guard features a V-cut for accurate placement on your records. This premium build offers consistent playback and long-term reliability for discerning vinyl lovers who want every spin to sound its absolute best.

Audio-Technica AT-VM745xML VMx Microlinear Phono Cartridge Red/Gold
Audio-Technica AT-VM745xML VMx Microlinear Phono Cartridge Red/Gold
Audio-Technica AT-VM745xML VMx Microlinear Phono Cartridge Red/Gold

Features

  • AT-VMx dual moving magnet design delivers lifelike stereo sound reproduction
  • Microlinear stylus accurately traces grooves for nuanced audio clarity
  • Solid boron cantilever ensures precise response to musical dynamics
  • PCUHD coils provide rich sound with excellent transient response
  • Paratoroidal coils enhance channel separation and stereo imaging
  • Threaded inserts allow easy mounting with just two screws needed
  • Die-cast aluminum housing reduces vibrations for cleaner audio output
  • V-cut stylus protector guides precise placement onto record grooves

Specs

Cartridge
  • Type: Dual Moving Magnet
  • Stylus: Microlinear
  • Cantilever: Solid Boron
  • Frequency Response: 20Hz–27kHz
  • Coil Material: PCUHD (Pure Copper Ultra High Drawability)
  • Coil Configuration: Paratoroidal
Construction
  • Body Material: Die-Cast Aluminum
  • Shield Plate: Center Plate
Compatibility
  • Mounting: Threaded Inserts (Requires Two Screws)
  • Stylus Protector: V-Cut
  • Turntable Fit: 1/2" Mount Headshells
