Description

The CM.203 CD mixer features dual top-loading CD players and 2 line inputs for your iPod and other portable media devices so you can easily access a variety of music sources!

The CD section features ±8% pitch control with pitch bend, relay play, and a fader start feature that lets you automatically play the cued song when you fade over to a channel without having to press a button.

The CM.205 is iPod ready and includes one iPod cable for plug-and-play connectivity. The mixer also features gain and 3-band EQ (+9/-26) controls on each channel, a user-replaceable crossfader, a 1/4" mic input with volume control, and a headphone output with cue pan.
Open Box Stanton CM.203 CD Mixer Level 1
Open Box Stanton CM.203 CD Mixer Level 1
Open Box Stanton CM.203 CD Mixer Level 1

Features

  • CD Section:
  • 8% pitch control with pitch bend
  • Fader start
  • Relay play
  • Mixer Section:
  • 2 line inputs to connect iPod, other MP3 device or more CD players
  • Gain and 3 band EQ (+9/-26) per channel
  • User replaceable crossfader
  • 1/4" mic input with volume control
  • Headphone output with cue pan
  • iPod Ready:
  • One iPod cable included for plug and play connectivity
  • iPod is a registered trademark of Apple Computer, Inc.

Specs

  • MIXER SECTION
  • THD+N (line): 0.01% at 1 kHz
  • S/N Ratio: (Dynamic Range): >90 dB
  • Noise Floor (line in put to any output): < -85 dBV
    Channel Fader Kill: < -85 dB @ 1 kHz
    Cross Fader Kill: 90 dB at 1kHz, 0 dB
  • Channel EQ: Hi +9 dB, -16dB @13HZ
  • Mid +9 dB, -23dB @1HZ
  • Low +9 dB, -23dB @70HZ
  • CD SECTION
  • Frequency Response (CD to master output): 20 Hz to 20 kHz +/- 2.0 dB
  • THD+N with 20 KHz Low Pass Filter: 0.05% at 1 kHz
  • S/N Ratio (ref: Full-Scale): >85 dB
  • MICROPHONE
  • Frequency Response (mic to master output): 20 Hz to 20 kHz +/- 2.0 dB
  • THD+N with 20 KHz Low Pass Filter: 0.05% at 1 kHz
  • S/N Ratio (ref: Full-Scale): >110 dB
  • INPUT/OUTPUT
  • Line Inputs: 2 x Stereo RCA -14 dBV/nominal input level 18 k Ohm unbalanced
  • Mic Input: 1x TRS -54 dBV/nominal input level 10k Ohm Balanced
  • Master Output: 2x RCA unbalanced nominal load 10k Ohms
  • Record Output: 2x RCA unbalanced -10dBV into 10k ohm load
  • Headphone Output: 1x 1/4" Phone Jack 1x 1/4" Phone Jack Max Load 32 Ohms
  • 1x 1/8" Mini Phone Jack
  • GENERAL
  • System: Compact Disc Digital Audio
  • Disc Loading: Top Loading
  • Display: 11 Digit LCD Display
  • Pitch Control Range: Within +/- 8%
  • Pitch Bend: +/- 8%
  • Pitch Accuracy: +/-0.15%
  • PHYSICAL
  • Dimensions: 440 (W) x 266(D) x110.5(H) mm
  • Weight: 4.4 Kgs.
  • Operation Temp.: 0 C to 40 C
  • Storage Temp: -20 C to 50 C
  • Power Source: 120V, 60Hz, AC 14W
