American DJ

Description

The Encore Profile Pro WW ellipsoidal from American DJ features a high powered 260W Warm White >97CRI 3,200K LED engine producing 10,000+ total lumens. It also features four blade manual framing shutters, manual focus, and supports B size metal HT transparency gobos. This is a DMX controlled electronic strobe with variable dimming curves and dimming modes and adjustable refresh frequency for flicker free operation for TV and FILM. The Encore Profile Pro also has locking 5-pin XLR In/Out and Locking Power In/Out, four button LCD control display panel, an integrated rigging yoke, quiet fan cooling and a multi-voltage universal auto switching power supply (AC100-240v).
American DJ Encore Profile Pro Mini WW 35W LED With DMX Black
American DJ Encore Profile Pro Mini WW 35W LED With DMX Black
American DJ Encore Profile Pro Mini WW 35W LED With DMX Black
warning

WARNING: This product can expose you to chemicals including Di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, and to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Specs

Source
  • 260W Warm White LED Engine
  • 50,000 Hour Average LED Life*
  • *LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
Photometric Data
  • >97CRI 10,000 Total Lumens* (*with 26° lens)
  •  3200K Color Temperature
Effects
  • Electronic Strobe and Dimming
  • Variable Dimming Curves and Dimming Modes
GOBOS
  • Supports “B” Size Metal, HT Transparency Gobos
  • GOBO Holder is included (See compatible Gobo Dimensions in Downloads section)
  • GOBOs are sold separately
Control/Connections
  • (3) DMX Channel Modes (2, 3, 6)
  • Adjustable Refresh Rates (900-1500, 25,000 Hz)
  • 4 Button Control Panel
  • LED Menu Display
  • Locking 5pin XLR Connector In/Out
  • Locking Power Connector In/Out
  • With Wired Digital Communication Network
  • RDM (Remote Device Management)
Size and Weight
  • Length: 26.9” (688mm) (Lens In)
  • Width: 11.375” (287mm)
  • Vertical Height: 17.7” (450mm)
  • Weight: 20.0 lbs. (9.1 kg)
Electrical/Thermal
  • Quiet Fan Cooling
  • AC 100-240V - 47/63Hz
  • 260W Max Power Consumption
  • Power Linking: 3pcs Max @120V / 8pcs Max @240V
  • 14° to 113°F (-10° to 45°C)
Included Items
  • 1 Locking Power Cable

Warranty

Warranty terms vary. Check with manufacturer for specific product warranty.
