Description

The RCF ART 815-A 15" 2-way powered speaker is designed for live events that demand greater low-frequency authority and room-filling output, making it well suited for DJ performances, full-band shows, larger parties, outdoor events, worship services and mobile PA systems. Its 1400W peak Class-D bi-amplifier powers a 15" woofer with a 2.5" voice coil and a 1" compression driver with a 1.75" voice coil, producing up to 130dB max SPL with a 45Hz–20kHz frequency response. RCF's True Resistive Waveguide, FiRPHASE processing and XBoost low-frequency enhancement help the ART 815-A deliver broad coverage, clear sound reproduction and full-range performance for live music, DJ playback, installed sound and portable reinforcement applications.

Bi-Amplified Power With Advanced DSP

The ART 815-A uses a 1400W peak Class-D bi-amplified design that separately powers its low- and high-frequency drivers for efficient performance and consistent output. Its DSP platform includes a 1600Hz crossover, thermal and RMS protection, a soft limiter and front-panel controls for volume, Boost and Mic/Line operation. FiRPHASE processing helps optimize phase response for more coherent sound, while XBoost enhances perceived low-frequency depth and richness when the speaker is used as a full-range cabinet without a subwoofer.

15" Woofer With Full-Range Performance

The 15" woofer gives the ART 815-A the deepest low-frequency extension in the ART 8 Series lineup, reaching down to 45Hz while maintaining high-frequency response up to 20kHz. A 1" compression driver provides vocal clarity and high-frequency detail, while the True Resistive Waveguide maintains consistent 100-degree horizontal and 60-degree vertical coverage. With up to 130dB max SPL, the ART 815-A is well suited for full-range DJ systems, live bands, larger speaking events and installations that require greater output and low-frequency presence from a single cabinet.

Reinforced Cabinet for Flexible Deployment

The ART 815-A is housed in a black PP composite cabinet with internal M-brace reinforcement to improve structural stability, reduce cabinet resonance and support demanding portable or installed use. A steel grille protects the drivers and front ports, while a 35 mm pole mount, 2 M10 rigging points and top and side handles support pole-mounted, wall-mounted, truss-mounted or flown configurations. Measuring 27.95" high, 16.33" wide and 16.15" deep while weighing 49.38 lb., the RCF ART 815-A 15" 1400W 2-way powered speaker combines high SPL capability, extended low-frequency performance and versatile deployment options for professional live-sound applications.

RCF ART 815-A 15" 1400W Powered Speaker
RCF ART 815-A 15" 1400W Powered Speaker
RCF ART 815-A 15" 1400W Powered Speaker

Features

  • 15" 2-way powered speaker with 1400W peak Class-D bi-amplification
  • 130 dB max SPL with 45 Hz–20 kHz frequency response
  • 15" woofer with 2.5" voice coil supports extended low-frequency output
  • 1" compression driver with 1.75" voice coil handles vocal and top-end detail
  • 100-degree x 60-degree True Resistive Waveguide provides wide coverage
  • FiRPHASE processing supports coherent response and clarity
  • XBoost low-frequency enhancement adds depth for full-range playback
  • XLR and 1/4" jack inputs with XLR output support PA routing
  • PP composite cabinet includes internal M-brace reinforcement
  • 35 mm pole mount, 2 M10 rigging points and integrated handles

Specs

General
  • Product type: Powered speaker
  • Series: ART 8
  • Model: ART 815-A
Power Handling & Supply
  • Amplifier type: Class-D bi-amplification
  • Total power: 1400W peak
  • High-frequency power: 400W peak
  • Low-frequency power: 1000W peak
  • Cooling: Convection
  • Power connection: VDE
Preamp & DSP
  • DSP: FiRPHASE, XBoost
  • Crossover frequency: 1600Hz
  • Protections: Thermal, RMS
  • Limiter: Soft limiter
  • Controls: Volume, Boost, Mic/Line
Speaker Configuration
  • Speaker type: 2-way active
  • Woofer: 15" with 2.5" voice coil
  • Compression driver: 1" with 1.75" voice coil
  • Waveguide: True Resistive Waveguide
Audio Performance
  • Frequency response: 45Hz–20kHz
  • Max SPL: 130dB
  • Horizontal coverage angle: 100-degree
  • Vertical coverage angle: 60-degree
Connectivity
  • Input signal: Balanced/unbalanced
  • Input connectors: XLR, 1/4" jack
  • Output connector: XLR
  • Input sensitivity: -2 dBu/+4 dBu
  • Mic input sensitivity: -32 dBu
Construction
  • Cabinet material: PP composite
  • Cabinet reinforcement: Internal M-brace
  • Grille: Steel
  • Color: Black
  • Handles: 1 top, 1 each side
  • Rigging points: 2 M10
  • Pole mount: 35 mm insert
Dimensions and Weight
  • Height: 27.95"
  • Width: 16.33"
  • Depth: 16.15"
  • Weight: 49.38 lb.
