Eventide Mixing Link Mic Pre w/ FX Loop
Description
This I/O station for multiple devices has many typical uses, but its versatility lends it a universal usefulness that can adapt to many different challenges in the studio, the rehearsal room or on stage.
Features
- FX Loop Send and Return supports Balanced and Unbalanced signals - interfaces with consoles or guitar pedals easily
- Latching or Momentary Footswitch control of FX Loop for performance effects
- Works with a wide range of microphones including condenser and ribbon mics with up to 65dB of clean gain
- Aux I/O connection supporting stereo input and send
- Guitar Amp output and Headphone monitor output with separate master volume control
- International universal power supply included
- Operates on 9V battery
- No phantom power)
- 48V Phantom power for Condenser mics
- Balanced XLR Output which supports DI and Line levels
- Instrument and Balanced Line level inputs
- Versatile Mix Control supports 3 modes- 100% Mic w/FX blended in, or Mic/FX balance control, or 100% FX (no Mic)
Specs
Analog input
- Inst in: +10dbu, 500k?
- XLR line in: +24dbu, 22k?
- XLR mic in: +4dbu, 2k?
- From FX: +10db, 200k?
- Aux in: +4dbu, 5.0k?
- To fx: +10dbu, 400?
- To amp: +10dbu, 250?
- Phones: 150mw per channel, min load = 8 ohms
- Di/line out: (di) -10dbu, (line) +18dbu, 200?
- Aux out: 18mv, 200? (mobile mic level)
- 9 VDC, 500 ma, center pin (-)
- Minimum required current at 9VDC = 200mA
Warranty
One year parts and labor warranty.
