collapse expand iconDescription

The E 210 Sub AS system subwoofer comes with two 1,200-watt amps. Power amp number one drives the two internal 10″ woofers, with plenty of juice left over to run an external passive type L Sub 1200. The second power amp delivers 900 watts at 2.6 ohms to drive up to three E 835s (or six E 435s).

collapse expand iconFeatures

  • Subwoofer with two 1.200-watt amplifiers
  • Two 10″ woofers
  • Covers larger sound reinforcement applications
  • Drives up to six E 435 / three E 835 line source loudspeakers
  • Additional Speakon output for connecting an add-on L SUB 1200 bass bin
  • Four filters (variable to match the number of mid/high line sources)
  • Two E-Connect couplers with an integrated signal bus

collapse expand iconSpecs

Speaker Configuration
  • Active/passive: Active
  • Type: Subwoofer
  • LF driver: 2 x 10"
Power
  • Amplifier class: D
  • Wattage: 2400W
  • Mixer/preamp: No
Audio
  • Frequency response: 38 Hz - 150 Hz
  • Coverage pattern: Not applicable
Inputs
  • XLR Combo: 1
Outputs
  • XLR: 2
  • SPEAKON: 2 (1 Sub, 1 Mid/High)
Enclosure
  • Width: 38 cm
  • Height: 67 cm
  • Depth: 56 cm
  • Weight: 80.8 lb.
