Description
The AKG C314 is one in a series of microphones designed around the characteristics of the now classic AKG C414. The C314 has the exact same one-inch dual diaphragm capsule as the C414 XLS, a sound embraced by audio engineers the world over. Designed for enthusiasts and professionals alike, the C314 has advanced features that help artists fine-tune their signature sound including four selectable polar patterns, the lowest self-noise in its class, and an overload detection LED. Whereas the C414 features nine polar patterns, the C314 offers the four most commonly used polar patterns in studio applications.
Four selectable polar patterns
Perfect for nearly every application.
Lowest self noise
For highest resolution in high dynamic applications.
Overload detection LED
Indicates overly high sound pressure levels.
Computer-matched diaphragms
To guarantee the highest polar pattern accuracy.
Integrated capsule suspension
Reduces mechanical noise and resonances.
20 dB attenuation pad and bass-cut filter
For close up recording and reduction of the proximity effect.
Four selectable polar patterns
Perfect for nearly every application.
Lowest self noise
For highest resolution in high dynamic applications.
Overload detection LED
Indicates overly high sound pressure levels.
Computer-matched diaphragms
To guarantee the highest polar pattern accuracy.
Integrated capsule suspension
Reduces mechanical noise and resonances.
20 dB attenuation pad and bass-cut filter
For close up recording and reduction of the proximity effect.
Features
Audio
- Frequency response: 20Hz to 20kHz
- Max SPL: 135 dB
- Connectivity: XLR
- Capsule: Condenser
- Pattern: Multi-pattern
- Type: Mounted
- Applications: Studio, stage
- Phantom power required: Yes (48V)
- Width: 6.3" (160 cm)
- Height: 1.7" (43 mm)
- Depth: 2.16" (55 mm)
- Weight: 10.58 oz. (300 g)
- Case: Pouch
- Clip: Shock mount
- Power supply: No
